OS Engines 51012110 OMA-3825-750W Brushless, Outrunner Electric Motor (OSM51012110)

51012110 Brusless Outer Motor OMA-3825-750W

BRAND : OS Motor

Product Code:51012110

Product Features:

Weight 190g
POLES 14
Beareings 3
Current Range 30 - 40A
ESC Timing Degrees 20 - 30 Degrees
KV RPM 750
Max Current 75a for 10 Secs
Resistance 31 Mohms
Turns 12
Power Output 590W
Nominal Voltage 12.6V (3S Li-Po) 16.8V (4sli-Po)
No Load Current 2.0a
Max Effeciency 85%
Shaft Dia 5mm.
Shaft Length 11.5 mm.

EXPLANATION :

Operating The system should be designed.
Reinforced central body and large ball bearing.
Made of durable and stainless steel.
Extra work and reliability balance is provided for each engine.
There is a 3.5 mm gold connector.
Battery 4 or 5 cell lipo must be used.
2-time 25-32 aircraft engine.

NOTE:

You need to complete this model
auxiliary materials
"Together with this product
Other products required "
You can review and buy together on the tab.


OMA-BRUSless Motor 3825-750W
